Design: Squire Body
Rating: Up to 15,000 psi @ 14°F to 176°F
Connection: BSP, NPT, BSPT, UNF & Other Thread on Request
Size: 1/4” to 1”
Connections: Screwed
Body Stock: Bar Stoke & Forged Steel
Material: SS, CS and other Material on Request
Rating: Up to 20,000 psi @ 14°F to 176°F
Connection: BSP, NPT, BSPT, UNF & Other Thread on Request
Size: 3/16", 1/4", 3/8", 1/2", 3/4", 1"
Connections: Screwed
Body Stock: Bar Stoke & Forged Steel
Material: SS, CS and other Material on Request
Rating: Up to 20,000 psi @ 14°F to 176°F
Connection: BSP, NPT, BSPT, UNF & Other Thread on Request
Size: 3/16", 1/4", 3/8", 1/2", 3/4", 1"
Connections: Screwed
Body Stock: Bar Stoke & Forged Steel
Material: SS, CS and other Material on Request
· Type: Screwed Bonnet Needle Valve
· Rating: Up to 6,000 psi @ up to 1200ºF
· Stem: Needle tip (Standard), Non routing (Optional)
· Seat: Standard Metal to Metal Soft Seat (Optional)
· Handle: Removable Size: 1/8” to 2”
· Connections: NPT, BSP, BSPT, Socket Weld, But Welded Flanged Body
· Stock: Bar Stoke
· Material: SS, CS and other Material On Request
· Type: Screwed Bonnet Needle Valve
· Rating: Up to 15,000 psi @ up to 1200ºF
· Stem: Needle tip (Standard), Non routing (Optional)
· Seat: Standard Metal to Metal Soft Seat (Optional)
· Handle: Removable Size: 1/8” to 2”
· Connections: NPT, BSP, BSPT, Socket Weld, But Welded Flanged Body
· Stock: Bar Stoke
· Material: SS, CS and other Material On Request
Working Pressure : Up to 20 000 psig (1379 bar)
Temperature :–65 to 1562°F (–18 to 850°C)
Body Material :316 stainless steel, alloy 400, alloy 20, alloy 600, alloy C-276, titanium
Flow Coefficient :Up to 2.4
End Connections
Type :NPT, tube socket weld, pipe socket weld, male fitting, male fitting
Size :1/8 to 1 in.; 6 to 12 mm
Working Pressures : Up to 6000 psig (413 bar)
Temperature : –50 to 400°F (–45 to 204°C)
Nominal Cracking Pressure
Fixed : 1/3 to 25 psi (0.02 to 1.7 bar)
Adjustable : 3 to 600 psi (0.21 to 41.4 bar)
Body Material : 316 stainless steel, brass
Seal Material : Fluorocarbon FKM, Buna N
Flow Coefficient : 0.10 to 4.7
End Connections
Type : Swagelok tube fittings, NPT, ISO, SAE/MS, VCO® O-ring fittings, VCR® face seal fittings
Size : 1/8 to 1 in.; 6 to 25 mm
Working Pressures : Up to 10000 psig (700 bar)
Temperature : –50 to 600°F (–45 to 315°C)
Nominal Cracking Pressure
Fixed : 1/3 to 25 psi (0.02 to 1.7 bar)
Adjustable : 3 to 600 psi (0.21 to 41.4 bar)
Body Material : 316 stainless steel, brass
Seal Material : Fluorocarbon FKM, Buna N
Flow Coefficient : 0.10 to 4.7
End Connections
Type : Swagelok tube fittings, NPT, ISO, SAE/MS, VCO® O-ring fittings, VCR® face seal fittings
Size : 1/8 to 1 in.; 6 to 25 mm
Working Pressures : Up to 15000 psig (700 bar)
Temperature : –50 to 600°F (–45 to 315°C)
Nominal Cracking Pressure
Fixed : 1/3 to 25 psi (0.02 to 1.7 bar)
Adjustable : 3 to 600 psi (0.21 to 41.4 bar)
Body Material : 316 stainless steel, brass
Seal Material : Fluorocarbon FKM, Buna N
Flow Coefficient : 0.10 to 4.7
End Connections
Type : Swagelok tube fittings, NPT, ISO, SAE/MS, VCO® O-ring fittings, VCR® face seal fittings
Size : 1/8 to 1 in.; 6 to 25 mm
Working Pressures : Up to 20000 psig (1379 bar)
Temperature : –50 to 600°F (–45 to 315°C)
Nominal Cracking Pressure
Fixed : 1/3 to 25 psi (0.02 to 1.7 bar)
Adjustable : 3 to 600 psi (0.21 to 41.4 bar)
Body Material : 316 stainless steel, brass
Seal Material : Fluorocarbon FKM, Buna N
Flow Coefficient : 0.10 to 4.7
End Connections
Type : Swagelok tube fittings, NPT, ISO, SAE/MS, VCO® O-ring fittings, VCR® face seal fittings
Size : 1/8 to 1 in.; 6 to 25 mm
